机器特点

◆本机是对合金圆锯片焊接齿台进行研磨的专用自动化设备。

◆机械手上下锯片，操作简洁方便，一人可操作10台以上。

◆行程由电机提供动力，可精却控制研磨深度。

◆可加工驼峰齿等特殊齿型。

Machine features

    1.This machine is a specialized automated equipment for grinding the welding tooth table of alloy circular saw blades.

    2.Using a robotic arm to move the saw blade up and down, the operation is simple and convenient, and one person can operate more than 10 machines.

    3.The stroke is powered by an electric motor, which can accurately control the grinding depth.

    4.Can process special tooth shapes such as hump teeth.

技术参数Technical parameter

◆锯片直径Blade Diameter   φ110—φ400mm

◆齿距范围Range of tooth pitch   7—50mm

◆适用齿厚Applicable tooth thickness   ≤3.5mm

◆砂轮规格Grinding wheel specifications   φ255×φ25.4×2.5mm

◆砂轮行程Grinding wheel stroke   0—25mm

◆工作次数Work frequency   40—60T/min

◆工作气压Working air pressure   ≥0.45MPa

◆电源电压supply voltage  AC380V50Hz  V

◆功    率Power   2.5KW

◆重    量Weight   600Kg

◆机床尺寸Machine tool dimensions    1050×1300×1800mm
